现在位置首页>自动化仪器仪表>温度仪表>温度仪表校验装置> ON-406-PP_ON-409-PP_ON-410-PP热敏电阻探头OMEGA欧米茄

商品编号:74283
分享

ON-406-PP_ON-409-PP_ON-410-PP热敏电阻探头OMEGA欧米茄

价    格:询价

产    地:美国更新时间:2019/9/11 7:42:53

品    牌:欧米茄型    号:ON-406-PP

状    态:正常点击量:42

15221105376
联系我时,请说明是在来宝网上看到的,谢谢!

上海茂培电子科技有限公司

联 系 人:范先生

电     话:15221105376

传     真:

等     级: (第 4年)

性     质:贸易型,

联系我时请说在来宝网上看到的,谢谢!




ON-406-PP_ON-409-PP_ON-410-PP热敏电阻探头OMEGA欧米茄

精密热敏电阻


多种风格,满足多种应用


电话插头标准


25摄氏度时为2252欧姆


欧米茄工程系列“400”探头用于实验室和研发应用,并具有


可互换传感器精度为±0.1°C。每个传感器都配有一根10英尺长的乙烯基电缆和


电话插头。“400”系列探头在25°C时为2252欧姆。



产品参数

ON-406-PP_ON-409-PP_ON-410-PP热敏电阻探头OMEGA欧米茄

Precision Thermistor

Various Styles to Meet Numerous Applications

Phone-Plug Connector Standard

2252 Ohm @ 25 Degrees C

OMEGA ENGINEERING Series "400" probes are for use in laboratory and R&D applications and have

interchangeable sensor accuracy of ±0.1°C. Each sensor is supplied with a 10-foot vinyl cable and

phone-plug connector. The Series "400" probes are 2252 Ohm @ 25°C.



产品介绍

ON-406-PP_ON-409-PP_ON-410-PP热敏电阻探头OMEGA欧米茄

OMEGA ENGINEERING Series "400" probes are for use in laboratory and R&D applications and have
interchangeable sensor accuracy of ±0.1°C. Each sensor is supplied with a 10-foot vinyl cable and
phone-plug connector. The Series "400" probes are 2252 Ohm @ 25°C.

Configuration
Dimensions in mm (")
Model
Number
DescriptionTemp.
Rating
Application
ThermistorON-401-PPGeneral Purpose. Used for short-term water and sub-soil readings. Most rugged, waterproof construction.100°C
(212°F)
Buried
ThermistorON-401-PP-VWater resistant, soft, flexible, vinyl tipped version of above model.
ThermistorON-402-PPSmall Flexible. Vinyl sheath and tip. Cuvette temperatures. General purpose measurement. Continuous length.100°C
(212°F)
General Purpose
ThermistorON-403-PPTubular. Stainless steel probe for rugged duty. Often used for liquid immersion. Probe is immersible only to cap.100°C
(212°F)
Liquid
ThermistorON-404-PPTubular-Glass. Chemically inert for liquid immersion use. Thermometric titration. Freezing point determination. Pyrex, 127 mm (5") long.100°C
(212°F)
Liquid
ThermistorON-405-PPAir Temperature. Stainless steel probe suitable for test rooms, incubators, remote air readings, monitoring of gas streams, etc.100°C
(212°F)
Gas
ON-406-PPSame as ON-405-PP but with economical plastic housing.
ThermistorON-408-PP"Banjo" Surface Temperature. Skin, oral, axillary, water bath, air, surfaces temperatures. Stainless steel.100°C
(212°F)
Surface
ThermistorON-409-PPAttachable Surface Temperature. Stainless steel cup, epoxy-backed. Easy to tape on flat surfaces. Good for heat loss or compression efficiency study of piping.100°C
(212°F)
Surface
ThermistorON-410-PPTubular With Fitting. Rugged, stainless steel probe with pipe fitting.Suitable for taking readings in pipes or inside closed vessels.100°C
(212°F)
Gas, Liquid
